Hello friends welcome to FreeCAD tutorial in our previous tutorial we have learned Model Model Arm Bracket in FreeCAD. In this tutorial we will do modeling in FreeCAD with the help of Part design workbench of FreeCAD. You can also download my source file of the tutorial at https://mechnexus.com/mechnexus-youtube-tutorial-source-file/ so let’s start our tutorial.
Select the top plane and create below sketch.
Now create the pad of 10mm as shown in below image.
Now select the top face and create below sketch by projecting outer radius.
Now create the pad of 40mm as shown in below image.
Now create the datum plane at distance of 32mm as shown in below image.
Now select the datum plane and create below sketch.
Now add the material as shown in below image.
Now select the face and create below sketch.
Now create the pad as shown in below image.
Now select the top face and create below sketch.
Now create the pad of 10mm as shown in below image.
Now select the top face and create below sketch.
Now create the pad as shown in below sketch.
Create the hole sketch as shown in below image.
Create the hole as shown in below image.
