description in this tutorial we will
0:53
model the multiple steps shaft without
0:56
creating the sketch with the help of a
0:59
sha design result so let's start our
1:02
tutorial I will uh close this file I
1:05
will uh go to the part
1:07
design first I will create a new file
1:10
then go to the part design and I will
1:12
click on Sha design visit so here you
1:21
uh diameter of 50 and
1:24
60 length shaft has been
1:28
created and I can add multiple steps to
1:33
my shaft for this click on the column
1:36
and then click on ADD column then again
1:39
click and click on ADD column so you can
1:42
see that uh steps is getting
1:48
then you can click and then add column
1:54
then add column so this way you can
1:56
create the multiple steps shaft
2:00
and from here you can modify the values
2:03
of each steps like length you can change
2:06
the length from here diameter you can
2:10
change from here if you have the inner
2:14
diameter then you can also give from
2:17
here and uh if you want to plot some
2:22
graph then you can also get the graph
2:27
here but I'm not going much just into
2:30
deep about the constraint
2:36
type so here we have created a shaft
2:40
just by copying the column and changing
2:44
the value now let's see what happens if
2:47
we click on okay so once you click on
2:51
okay so you can see that a Revol shaft
2:54
has been created here the best thing
2:57
about this uh design wizard
3:01
is a sketch has been created and once
3:04
you click on edit sketch then you can
3:06
get the diameter and length of each step
3:12
and you can easily modify it from
3:18
here so this is how you can model the
3:22
multiple step shaft in free care with
3:25
the help of a shaft design wizard I hope
3:30
you have liked this tutorial thank you
3:32
for watching and thank you for your
