Hello friends Welcome To freead tutorial
0:02
and in this tutorial we will learn
0:04
extrude feature of a freead so here I
0:08
have uh launched my free Cad and I will
0:13
file you can also visit my website Mech
0:16
nexus.com where I write articles and
0:19
tutorials on freead you can download my
0:23
tutorial source file from the here if
0:26
you like my method of teaching then
0:29
please support me on coffee.com you can
0:32
buy me a cup of coffee your small
0:36
support will help these channels to grow
0:38
and it will motivate me to create more
0:43
freead I will provide my website and my
0:47
Kofi donation page Link in a video
0:49
descriptions so let's come back to our
0:54
tutorial and before starting let's
0:57
understand the concept of a body body
1:03
part so body is uh anything which we
1:08
made in a free cat and part is work as a
1:13
container for example I create a body
1:16
here I create one more
1:20
body and now if I click on the part then
1:24
part get inserted in my browser and now
1:30
simply drag my body inside the
1:36
part so you can see that uh this part is
1:42
container so it is your
1:46
choice you use this part or not but it
1:50
is recommended from my end it is very
1:54
useful to store the multiple bodies so
1:58
first insert a part and then create a
2:04
let's create a new file and uh to
2:09
understand the extrude features I will
2:11
simply select a body and
2:15
now you can see that uh nothing is
2:22
interface so click on origin and press
2:25
the space bar so that uh dat planes and
2:30
datm access will be visible now here you
2:34
will have the options to select the
2:36
plane I would prefer the front plane I
2:40
will select it and click on the
2:44
sketch now go to the model Tab and press
2:47
the space bar to hide
2:50
the datm plane and access now to
2:55
understand extrude features I will
2:57
simply create a rectangle
3:01
and uh I will make it symmetric so I
3:03
will select the symmetricity constraint
3:07
point this point and origin
3:11
point now our uh rectangle is symmetric
3:16
now I will select the line select on
3:19
horizontal Dimensions give the 200
3:21
Dimensions I will select the vertical
3:24
line and give the vertical dimension of
3:26
100 say okay so our our sketch is fully
3:30
constrained and it turns into the
3:33
green now I will go to the task Tab and
3:38
here I can see the constraint and here I
3:41
can see the entities of my
3:44
sketch now I will close
3:47
it now I will click on the pad so once I
3:52
click on the pad you can see that the
3:54
pad length so that uh here I can give my
3:58
length let's I give it
4:00
60 so you can see that it is extruding
4:06
only I can make it symmetric so click on
4:10
symmetric to the plane and now go to the
4:13
model and On the Origin plane so you
4:16
will see that now our Extrusion is
4:19
symmetric and if I uncheck it then my
4:22
Extrusion will be in one
4:27
directions and uh now I will uh say
4:35
okay now here we will uh understand what
4:42
Dimensions so two Dimension is used when
4:49
unsymmetric length for example in One
4:52
Directions I want 100 and in other
4:57
500 so you can can see that this is
5:03
Extrusion now let's understand what is
5:06
up to phase so for this we will go with
5:11
Dimension and make it symmetric to the
5:13
plane of 100 mm and say okay now to
5:20
understand the up to face Extrusion I
5:22
will on my origin plane and I will
5:25
select my front plane and click on the
5:30
so here on uh Direction in Z directions
5:35
I will give the 250 distance so you can
5:38
see that a DAT temp plane is created and
5:41
I will say okay off my origin place by
5:46
pressing the space bar now you can see
5:49
here Blue Tick symbol it is a for the
5:51
rebuilt so click on refresh icon or
5:55
press the FY from your keyboard now I
5:59
will create a sketch on my datm plane so
6:04
select the datm plane and click on the
6:06
sketch and now here I will uh create a
6:13
circle and uh select this circle and
6:16
give the diameter Dimensions let's see I
6:25
it now I will off my datm plane now I
6:29
will uh select my circle and click on
6:33
the pad so you will see that you are not
6:36
seeing anything on a screen for this
6:41
reverse and from here click on up to
6:46
face so here the face I will give this
6:51
face so you can see that uh this
6:54
Extrusion go up to the dis
6:57
phase here you can see that that
6:59
selected face is a pad
7:03
F6 so if I wanted to change my face then
7:08
I can also select the my back
7:11
phas so Extrusion goes up to the that
7:20
now this is the very uh basic
7:24
introduction about the extrude features
7:26
so this is all about this tutorial
7:30
extrude feature in free CAD thank you
