Hello friends welcome to Free tutorial
0:03
and in this tutorial we will learn
0:06
material texture and rendering in a free
0:09
CAD you can also visit my website Mech
0:12
nexus.com where I write articles and
0:15
tutorials on freeat you can also
0:18
download my tutorial Source F from the
0:21
here you can also support my work by
0:24
buying my free cat crash course for
0:26
beginner it is a very basic level course
0:30
for the beginner user where a beginner
0:32
user can Master the free
0:35
Cad and you can also support my work on
0:38
coffee.com you can buy me a cup of
0:41
coffee you will get my website link and
0:44
my Kofi donation page Link in a video
0:50
description after the modeling of our
0:53
part in free CAD we can apply the
0:56
material in a part design workbench
1:00
click on your last feature and go to the
1:02
appearances section and here you will
1:06
get option for the material drop down it
1:08
and apply your design material for
1:11
example I wanted to apply the copper
1:15
close it so you can see that uh copper
1:18
material has been applied to my part
1:23
now uh if you want to check the weight
1:26
density of your part so for this you can
1:29
and install a micro known as a fc
1:33
info here I have installed the micro FC
1:36
info you can install it by going to the
1:42
manager and here filter the
1:52
info so you will get this micro FC
1:55
info install it I have already installed
1:59
it so I will directly run this
2:02
micro so I will go to the micro click on
2:06
micro click on FC info and click on
2:11
execute close this report View and
2:15
now here on FC info I will select my
2:20
material which is the
2:24
copper so you can see that here weight
2:28
section is a 18.8 kg my part total
2:32
weight is a around 19 kg and you will
2:37
get much more info about your part so
2:40
this is a very useful macro that uh
2:47
CAD it also give the moment of
2:54
you go to the here and if you scroll
3:02
get moment of inertia with
3:06
mass you will get the center in x y and
3:10
Zed you will get the material cost as
3:20
price so this is how you can apply the
3:23
material and you can get its weights and
3:30
we will remove this uh
3:33
material and we will go with the
3:36
default now how we can apply the texture
3:40
so for the texture you can search over
3:43
the internet for the texture for
3:48
example I wanted to apply the bronze
3:53
texture so you can search over the
3:56
internet on Google or in searching
4:02
can type here the bronze material and
4:05
you choose any texture and open this
4:08
image and save the image try to
4:15
use uh creative common license
4:18
images and I have uh saved the bronze
4:22
texture image and I will apply to my
4:25
part to apply the texture
4:31
click on the body go to the view and
4:34
click on the texture mapping on here
4:37
texture mapping give the path of your
4:40
texture so here is a bronze material
4:44
texture I will select it and say
4:48
open so you can see that uh bronze
4:52
textures has been applied to my
4:57
part this is the very good tool to but
5:00
problem with this tool is once you click
5:02
on the close the texture will be
5:06
disappeared so this tool is
5:10
useful if you want to capture some
5:13
images or you want to send the images to
5:17
your client after the applying the
5:20
material so this is how you can apply
5:24
any textur to your prodct for example
5:27
aluminium steel bronze copper
5:31
Etc and you can take a screenshot and
5:35
use on social media your blog or you can
5:41
client so we have learned how we can
5:46
material and we can get the weight and
5:49
other properties in second we have
5:52
applied the textures we have applied
5:55
bronze textures to our part now we will
5:58
learn how how we can render our part
6:06
to render our part in a cad we will
6:10
use CAD software of the open cascet so
6:15
visit the website open
6:18
Cascade and uh if you are not able to
6:23
CES in the navigation sections so here
6:27
is a search bar just type
6:36
enter so here you will get the address
6:39
which is a free to use click on it
6:43
create an account on open casate and
6:51
1.0 I have already download downloaded
6:55
it and I will show you how you can
6:57
render the part in a cat is so once you
7:05
CAD it will be in a zip file double
7:08
click on the zip file and
7:11
uh open it you can also extract it so
7:15
after the extract you will see here one
7:18
file known as a cad r.
7:27
it address will will be get launched now
7:32
here we will render our parts to render
7:35
our part we will export it into the step
7:39
file so I will click on the body and I
7:46
export and I will export
7:55
file and here I will click on export
7:58
visible object object and Export single
8:01
object placement and I will say
8:04
okay so my part has been exported into
8:08
the step now go to the file
8:15
import and here I will insert my part so
8:20
here in on the import setting just click
8:26
import so you can see that uh
8:30
my part has been imported in a
8:33
cad now click on the transform
8:39
section select first select your
8:41
imported part click on the transform
8:44
section so you will get here
8:48
UCS go to the rotational and from here
8:52
you can rotate your part so I
8:55
will keep my part position as I
9:05
desired something like
9:25
this I will keep in this position now
9:29
here on the cad R go to the material
9:32
section as you can see that
9:36
uh it uh automatically selected as a
9:40
brass if I click on it then I can give
9:45
steel so you can see that steel textures
9:53
or I can give any other material as of
9:57
my choice for example
10:05
bronze you can zoom in and zoom out and
10:09
from the here in a export option you can
10:13
export is as a address script or you can
10:21
file give any name and save
10:25
it so you can see that we have a Rend
10:29
our part and we have save it as an image
10:34
and now you can use this part as a
10:37
render image in your blog social website
10:41
or you can send to your client this
10:46
image with Cades you can do so many
10:49
others things it's customization
10:54
orthographic there are so many things so
11:00
render our part in a cad
11:03
R so this is all about this tutorial how
11:07
to texture mapping in a free Cad and how
11:11
to render the part in a cad R so this is
11:17
tutorial thank you for watching and
11:20
thank you for your valuable
