In FreeCAD, the “Check Geometry” tool (also called “Part → Check Geometry”) is used to analyze and validate 3D shapes for errors like non-manifold edges, self-intersections, or invalid topology. This is especially useful before performing Boolean operations (Union, Cut, Common) or exporting to other formats (STEP, STL).
Related posts:
- Enhance your Workflow: Essential FreeCAD Tips for Faster Modeling
- Time-Saving Benefits of FreeCAD Macros for Task Automation
- Getting Started with FreeCAD: Your No-Cost Solution for 3D Design
How to Use Check Geometry in FreeCAD-:
-
Select the Object
-
In the Model Tree or 3D View, select the object you want to check (e.g., a Part or PartDesign Body).
-
-
Run the Check Geometry Tool
-
Go to the Part Workbench.
-
Click Part → Check Geometry (or find it in the toolbar).
-
-
Review the Results-:
-
A dialog box will appear showing any errors or warnings.
-
Expand the “Issues” section to see details like:
-
Self-intersections (invalid for Booleans)
-
Non-manifold edges (edges shared by more than two faces)
-
Invalid faces or edges (degenerate geometry)
-
-
-
Fix Issues (If Found)-:
-
Refine the shape (
Part → Refine Shape). -
Use “Part → Shape Builder” to repair gaps.
-
Remodel problematic areas manually.
-
Common Errors & Fixes-:
| Error Type | Possible Fix |
|---|---|
| Self-intersections | Use Part → Refine Shape or remodel the intersecting area. |
| Non-manifold edges | Ensure no extra edges/faces exist; use Part → Explode Compound to inspect. |
| Missing/Invalid faces | Check for gaps in sketches; rebuild the extrusion. |
| “Not a solid” error | Ensure the shape is watertight (no holes); use Part → Convert to Solid. |
Additional Tips-:
-
Use “Part → Validate Shape” for deeper analysis (available in Python console via
Shape.check()). -
For STL exports, ensure the mesh is error-free (
Mesh → Analyze → Evaluate & Repair). -
Boolean operations fail? Check geometry first, then try
Part → Defeaturingto remove problematic edges.
💡 Pro Tips for Model Validation-:
-
Deep Analysis: For a more thorough inspection, use the Part → Validate Shape tool. You can also access this function via the Python console using
Shape.check(). -
Prepare for Export: Before exporting to STL, ensure your solid is error-free. If working with meshes, use Mesh → Analyze → Evaluate & Repair.
-
Troubleshoot Operations: If Boolean operations (like Union or Cut) are failing, run the Check Geometry tool first. If problematic edges are found, you can try using Part → Defeaturing to remove them.
