Hello friends welcome to FreeCAD tutorial in our previous tutorial we have learned FreeCAD user Interface. In this tutorial we will do FreeCAD Part Modeling Tutorial 52 with the help of Part design workbench of FreeCAD. You can also download my source file of the tutorial at https://mechnexus.com/mechnexus-youtube-tutorial-source-file/ so let’s start our tutorial.

Also Read-:

How to Easily Array Body in FreeCAD
How to Clone and Rotate Body in FreeCAD
Get Mass Properties, Weight, Volume and Area etc. in FreeCAD

Mechnexus freecad tutorial source file r10

Also Read-:

Model Locating Finger in FreeCAD
Model Toggle Lever in FreeCAD
Model Index Slide in FreeCAD

Step by Step Guide to Convert below drawing into 3D Model -:
00_01

00

First Select XY plane and create the below profile.

01

Now extrude the above profile by 16mm as shown in the below image.

02

Now create the datum plane at distance of 21 mm in Z direction at negative side as shown in the below image.

image_2023-09-18_065536778

Now select the Datum plane and create the below profile as shown.

image_2023-09-18_065925574

Now extrude the above profile to 22mm as shown in the below image.

05

Now select the Top face and create the below profile.

06

Now extrude the below profile by 3mm as shown in below image.

07

Now project the outer edge and create the below profile.

08

Now remove the material and set it to Through All as shown in below image.

09

Now select the back face and create the below profile.

10

Now extrude the above profile by 22mm as shown in below image.

11

Now give R3 fillet to all edges to our model as shown in below image.

12
