Hello Friends Welcome to new FreeCAD Tutorial in our previous tutorial we have learned how to setup Auto spacing in FreeCAD. In this Tutorial we will learn How to Model Socket Bearing in FreeCAD. In this Tutorial we will use Part Design Workbench to model our Socket bearing.
Also Read-:
| Things Anyone can do with FreeCAD |
| Let’s Explore the FreeCAD user Interface |
| List of Supported File Formats in FreeCAD |
First Select XY Plane and Create your Base Sketch which is Shown as below.
Once you created the fully constrained sketch exit from the sketch and extrude it as shown in below image.
Now select the front face and create the sketch as shown in the image.
As Sketch is Fully Constrained exit from the sketch and extrude it to 50mm. As shown in the image.
Now create a Circle on face and extrude it to length of 22mm. As shown in image.
Now on face create a circle of Diameter 16 and make through cut in my case I have selected distance.
Now Select top face and project outer edge arc and create 3 circle of Diameter 9 and make 3 Hole as shown in below image.
I hope yo have have enjoyed this tutorial if you have enjoyed it then please share it on social media and also give your valuable suggestion in the comment section of this tutorial. Your valuable comment will help me to improve quality of tutorial on this website.
